Bucket Capacity

1.50m³

Boom Length

6245mm

Arm Length

3100mm

Performance

Swing Speed

10.9rpm

Walking Speed

6.1/3.4/km/h

Mechanical System

Engine Mode

Isuzu 6HKI

Power Rate

212kw/2000rpm

Hydraulic System

Main Pump Type

Variable piston pumps

Main Pump Maximum Flux

2*288 l/min

Hydraulic Pump

Kawasaki

Control Valve

KYB

Tank Capacity

Fuel Tank

450L

Hydraulic Tank

290L

Body Size

Transport Size

10620mm(L) x 3200mm(W) x 3365mm(H)

Track Length

4940mm

Track Plate Width

600mm

Minimum Ground Clearance

506mm

Swing Radius at tail

3188mm

Scope of operation

Maximum Vertical Radius

8567mm

Maximum Digging Depth

7320mm

Maximum Digging Height

10243mm

Maximum Loading Height

2732mm

Maximum Vertical Digging Depth

4414mm
